轴承类型：；两个滚珠轴承
材料：；叶轮和；框架：塑料（UL94V-0）
引线：； UL1007 AWG26
；红线正极（+）
；黑线负极(一)
重量： 46.0克
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA06025_05L | B/S/F | 5 | 3.5~5.5 | 0.2 | 2500 | 4.6 | 7.3 | 24.2 |
| WSA06025_12L | B/S/F | 12 | 7.0~13.2 | 0.1 | 2500 | 4.6 | 7.3 | 28 |
| WSA06025_05M | B/S/F | 5 | 3.5~5.5 | 0.3 | 3500 | 6.5 | 10.2 | 27 |
| WSA06025_12M, | B/S/F | 12 | 7.0~13.2 | 0.15 | 3500 | 6.5 | 10.2 | 32 |
| WSA06025_05H | B/S/F | 5 | 3.5~5.5 | 0.45 | 4000 | 7.4 | 11.7 | 32 |
| WSA06025_12H | B/S/F | 12 | 7.0~13.2 | 0.3 | 4000 | 7.4 | 11.7 | 38 |
| WSA06025_12U | B/S/F | 12 | 7.0~13.2 | 0.45 | 4500 | 8.3 | 13.2 | 42.5 |
