轴承类型：；两个滚珠轴承
材料：；叶轮和；框架：塑料（UL94V-0）
引线：； UL1007 AWG26
；红线正极（+）
；黑线负极(一)
重量： 260.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA012038_24J | B/S | 24 | 14.0~26.4 | 0.18 | 2300 | 104.4 | 8.1 | 38 |
| WSA012038_12L | B/S | 12 | 7.0~13.2 | 0.4 | 2600 | 114.7 | 10.4 | 41 |
| WSA012038_24L | B/S | 24 | 14.0~26.4 | 0.32 | 2600 | 114.7 | 10.4 | 41 |
| WSA012038_48L | B/S | 48 | 28.0~56.0 | 0.14 | 2600 | 114.7 | 10.4 | 41 |
| WSA012038_12M | B/S | 12 | 7.0~13.2 | 0.5 | 2900 | 123.2 | 11.3 | 44 |
| WSA012038_24M | B/S | 24 | 14.0~26.4 | 0.4 | 2900 | 123.2 | 11.3 | 44 |
| WSA012038_48M | B/S | 48 | 28.0~56.0 | 0.28 | 2900 | 123.2 | 11.3 | 44 |
| WSA012038_12H | B/S | 12 | 7.0~13.2 | 0.8 | 3200 | 135.9 | 13.8 | 48 |
| WSA012038_24H | B/S | 24 | 14.0~26.4 | 0.46 | 3200 | 135.9 | 13.8 | 48 |
| WSA012038_48H | B/S | 48 | 28.0~56.0 | 0.3 | 3200 | 135.9 | 13.8 | 48 |
| WSA012038_12U | B/S | 12 | 7.0~13.2 | 1.3 | 4200 | 178.4 | 23.8 | 54 |
